METAFUSE OPENWEDGE PLATE
FOOT & ANKLE SYSTEM
![metafuse_openwedge_png 1 metafuse_openwedge_png 1](https://www.hnmmedical.com/wp-content/uploads/2018/01/metafuse_openwedge_png-1-615x275.png)
- MetaFuse Opening Wedge Plate Osteotomy
- Various Base Osteotomies (with plate size 0)
![](https://www.hnmmedical.com/wp-content/uploads/2018/02/MetaFuse-OpenWedge-PNG-300x234.png)
- Low Profile, only 1.3mm
- May use either 3.0mm or 3.5mm LS locking screws
- K-wire holes allow temporary fixation of the plate
and the osteotomy - Operated using the proven MetaFuse Instruments
- Available in 4 different size blocks (0, 2, 4 und 6
mm) for left and right foot - Slotted trapezoid shaped block to allow for bony
ingrowth or the use of bone substitutes in between
the osteotomy
![open wedge draco1 open wedge draco1](https://www.hnmmedical.com/wp-content/uploads/2018/01/open-wedge-draco1-500x300.png)
- Plates and screws made of titanium alloy
- High stabillity and load capacity due to anatomical shape of the platte
- Early weight bearing post-OP due to locking plate technique
SIZE
0
2
3
4
5
6
Item # (L)
HTR-03-120500
HTR-03-120602
HTR-03-200302
HTR-03-120704
HTR-03-200405
HTR-03-120806
Item # (R)
HTR-03-130900
HTR-03-131002
HTR-03-300603
HTR-03-130104
HTR-03-300705
HTR-03-130206
